Promise Technology Smartstor NS4600 User Manual

SmartStor NS4600 Product Manual
198
Choosing a Language
To choose a language, click the Language menu in the PASM Header and
choose the language you prefer.
Navigating in PASM
The Tree is the primary navigation tool in PASM. Categories of functions listed
with icons for different topics.
Icons for specific functions are listed under the categories. Click the icon to show
the functions.
Click the function icons to display their information on the screen. Each function
has one or more tabs in its screen.
The Tree expands and contracts in DHTML-capable browsers. If your browser
does not support DHTML, the Tree is expanded all of the time. The functions are
not affected.

Promise Technology Smartstor NS4600 Specifications

General

RAID levels	0, 1, 5, 10
Storage drive size	3.5 \
Hot-swap drive bays	Yes
Storage drive capacity	0 GB
Supported file systems	EXT3, FAT32
Storage drive interface	Serial ATA II
Total installed storage capacity	0 TB
Number of storage drives installed	4
Internal memory	0.25 GB
Processor model	-
Processor frequency	0.6 GHz
Maximum data transfer rate	1000 Mbit/s
Supported network protocols	FTP, DHCP, NTP
Compliance industry standards	IEEE 802.3i, IEEE 802.3ab, IEEE 802.3u
Certification	RoHS, CE, FCC, UL, TUV
Data transfer rate	3 Gbit/s
Dimensions (WxDxH)	152.5 x 229.6 x 188.2 mm
Power requirements	100 - 230 V/50-60 Hz
Networking features	Gigabit Ethernet
Compatible operating systems	Windows 2000/XP/2003/Vista Mac x 10.4 + Linux
USB 2.0 ports quantity	2
Ethernet LAN (RJ-45) ports	1
Power supply unit (PSU) capacity	90 W
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Weight	2500 g
