SmartStor NS4600 Product Manual
312
Figure 4. The PASM Event Log
4. Check the Event Log for reports of disk drive failure or other problems.
Responding to Events
All events are reported in the Event Log. Most events are simply reports that the
SmartStor is responding to your commands.
Many events are also reported via email. The SmartStor’s buzzer sounds for
serious events that require your attention.
A list of event categories is shown below:
• File System (page 312)
• NAS Replication (page 313)
• Snapshots (page 313)
• System (enclosure) (page 313)
• Disk Drives (page 314)
• RAID Volumes (page 314)
Reported Event Corrective Action
File System
File system of volume X
content errors! Check the
system before continuing.
The file system has a problem. Reboot the SmartStor
and check file system again. If the event appears
again, the file system has crashed. Rebuild the file
system. See page 310.

Promise Technology Smartstor NS4600 Specifications

General

RAID levels	0, 1, 5, 10
Storage drive size	3.5 \
Hot-swap drive bays	Yes
Storage drive capacity	0 GB
Supported file systems	EXT3, FAT32
Storage drive interface	Serial ATA II
Total installed storage capacity	0 TB
Number of storage drives installed	4
Internal memory	0.25 GB
Processor model	-
Processor frequency	0.6 GHz
Maximum data transfer rate	1000 Mbit/s
Supported network protocols	FTP, DHCP, NTP
Compliance industry standards	IEEE 802.3i, IEEE 802.3ab, IEEE 802.3u
Certification	RoHS, CE, FCC, UL, TUV
Data transfer rate	3 Gbit/s
Dimensions (WxDxH)	152.5 x 229.6 x 188.2 mm
Power requirements	100 - 230 V/50-60 Hz
Networking features	Gigabit Ethernet
Compatible operating systems	Windows 2000/XP/2003/Vista Mac x 10.4 + Linux
USB 2.0 ports quantity	2
Ethernet LAN (RJ-45) ports	1
Power supply unit (PSU) capacity	90 W
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Weight	2500 g
