Promise Technology Smartstor NS4600 User Manual

Chapter 7: Troubleshooting
313
File system capacity
usage of volume X is over
90%.
Reduce the number or size of the files or expand the
volume size. See “Migrating a RAID Volume” on
page 234.
File system capacity
usage of volume X is
100%.
Rebuilding file system... The file system is being rebuild by user action.
NAS Replication
NAS replication is
completed.
NAS replication has finished. Normal.
System is busy. NAS
replication is abort!
The RAID Volume is currently formatting, rebuilding,
or migrating. Wait until this process is done. Then try
the replication again.
System is doing another
replication. NAS
replication is abort!
The SmarStor is currently doing a replication. Wait
until the current replication is done. Then try the
second replication again.
NAS replication is failed! There is a failed network connection between the two
SmartStors. Correct the problem and try again. See
page 316.
Snapshots
The snapshot capacity
usage which timestamp is
[date and time] of volume
X is over 90%.
Move the snapshot volume to another storage
location.
Or delete the snapshot and then create a new one.
See page 243.
System is busy. Snapshot
creation was aborted!
The RAID Volume is currently formatting, rebuilding,
or migrating. Wait until this process is done. Then try
the snapshot again.
System is creating
another snapshot.
Snapshot creation was
aborted!
The SmarStor is currently doing a snapshot. Wait until
the current snapshot is done. Then try the second
snapshot again.
System (enclosure)
System is starting to work. Normal.
System is rebooting.
System is shutting down.
Reported Event Corrective Action

Promise Technology Smartstor NS4600 Specifications

General

RAID levels	0, 1, 5, 10
Storage drive size	3.5 \
Hot-swap drive bays	Yes
Storage drive capacity	0 GB
Supported file systems	EXT3, FAT32
Storage drive interface	Serial ATA II
Total installed storage capacity	0 TB
Number of storage drives installed	4
Internal memory	0.25 GB
Processor model	-
Processor frequency	0.6 GHz
Maximum data transfer rate	1000 Mbit/s
Supported network protocols	FTP, DHCP, NTP
Compliance industry standards	IEEE 802.3i, IEEE 802.3ab, IEEE 802.3u
Certification	RoHS, CE, FCC, UL, TUV
Data transfer rate	3 Gbit/s
Dimensions (WxDxH)	152.5 x 229.6 x 188.2 mm
Power requirements	100 - 230 V/50-60 Hz
Networking features	Gigabit Ethernet
Compatible operating systems	Windows 2000/XP/2003/Vista Mac x 10.4 + Linux
USB 2.0 ports quantity	2
Ethernet LAN (RJ-45) ports	1
Power supply unit (PSU) capacity	90 W
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Weight	2500 g
