Promise Technology Smartstor NS4600 User Manual

Chapter 7: Troubleshooting
315
Checking Enclosure Status in PASM
To check Enclosure status:
1. Start PASM.
See “PASM in your Browser” on page 193.
Or see “PASM in SmartNAVI” on page 194.
Or see “PASM in Bonjour” on page 196.
2. Click the Administration topic and choose the System icon to expand the
Tree.
3. In the Tree, click the System Information icon.
4. Click the Enclosure Information tab.
See Figure 5.
Migration or Rebuilding
on array X paused at Y%.
RAID Volume Migration or Rebuild was paused
temporarily by user action.
Migration or Rebuilding
on array X resumed at
Y%.
RAID Volume Migration or Rebuild was paused and
then resumed by user action.
Migration or Rebuilding
on array X completed.
RAID Volume Migration or Rebuild has finished.
Normal.
Migration or Rebuilding
on array X aborted at Y%
RAID Volume Migration or Rebuild was aborted
(stopped) by user action.
Migration or Rebuilding
on array X aborted at Y%
because of error.
RAID Volume Migration or Rebuild has aborted
(stopped) because of an error. Check the disk drives.
See page 306. Check the RAID Volume. See
page 308.
RAID status: "OFFLINE".
The NS4600 X volume Y
is offline.
Check the disk drives. See page 306. Replace the
failed drive. See page 307. Create a new RAID
Volume. See page 233.
RAID status: "CRITICAL".
The NS4600 X volume Y
is not functioning
correctly.
Check the disk drives. See page 306. Replace the
failed drive. See page 307. The RAID Volume will
rebuild automatically.
RAID X had some errors.
Formatting was aborted!
Check the disk drives. See page 306. Replace the
failed drive. See page 307.
Reported Event Corrective Action

Promise Technology Smartstor NS4600 Specifications

General

RAID levels	0, 1, 5, 10
Storage drive size	3.5 \
Hot-swap drive bays	Yes
Storage drive capacity	0 GB
Supported file systems	EXT3, FAT32
Storage drive interface	Serial ATA II
Total installed storage capacity	0 TB
Number of storage drives installed	4
Internal memory	0.25 GB
Processor model	-
Processor frequency	0.6 GHz
Maximum data transfer rate	1000 Mbit/s
Supported network protocols	FTP, DHCP, NTP
Compliance industry standards	IEEE 802.3i, IEEE 802.3ab, IEEE 802.3u
Certification	RoHS, CE, FCC, UL, TUV
Data transfer rate	3 Gbit/s
Dimensions (WxDxH)	152.5 x 229.6 x 188.2 mm
Power requirements	100 - 230 V/50-60 Hz
Networking features	Gigabit Ethernet
Compatible operating systems	Windows 2000/XP/2003/Vista Mac x 10.4 + Linux
USB 2.0 ports quantity	2
Ethernet LAN (RJ-45) ports	1
Power supply unit (PSU) capacity	90 W
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Weight	2500 g
