SmartStor NS4600 Product Manual
196
PASM in Bonjour
Bonjour is a service discovery protocol for local area networks. To use Bonjour,
you must have a Bonjour-capable browser. It is the default setting in Mac. For
Windows user, you can also download the software from Apple website.
Method 1
To log into PASM from Bonjour:
1. Click the Safari icon in the Windows application tray
or Mac Dock (right) to start your Browser.
2. Click the Show all bookmarks icon.
The Collections list appears.
3. Under the Collections list, click the Bonjour icon.
4. Click to highlight the SmartStor in the Bookmark list
to launch PASM.
Method 2
To log into PASM from Bonjour:
1. Click the Safari icon in the Windows application tray
or Mac Dock (right) to start your Browser.
2. Click the Bonjour icon.
The Bonjour list of network devices appears.
3. Click to highlight the SmartStor in the Bonjour list to
launch PASM.

Promise Technology Smartstor NS4600 Specifications

General

RAID levels	0, 1, 5, 10
Storage drive size	3.5 \
Hot-swap drive bays	Yes
Storage drive capacity	0 GB
Supported file systems	EXT3, FAT32
Storage drive interface	Serial ATA II
Total installed storage capacity	0 TB
Number of storage drives installed	4
Internal memory	0.25 GB
Processor model	-
Processor frequency	0.6 GHz
Maximum data transfer rate	1000 Mbit/s
Supported network protocols	FTP, DHCP, NTP
Compliance industry standards	IEEE 802.3i, IEEE 802.3ab, IEEE 802.3u
Certification	RoHS, CE, FCC, UL, TUV
Data transfer rate	3 Gbit/s
Dimensions (WxDxH)	152.5 x 229.6 x 188.2 mm
Power requirements	100 - 230 V/50-60 Hz
Networking features	Gigabit Ethernet
Compatible operating systems	Windows 2000/XP/2003/Vista Mac x 10.4 + Linux
USB 2.0 ports quantity	2
Ethernet LAN (RJ-45) ports	1
Power supply unit (PSU) capacity	90 W
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Weight	2500 g
