Promise Technology Smartstor NS4600 User Manual

Chapter 4: SmartNAVI
113
5. Optional. Click the arrow on the Date/Time header to reverse the
chronological order. (D)
Saving the Event Log
This function saves a copy of the Backup Event Log as a text file onto your PC.
The text file records the events displayed in the Event Log window.
Set the Event Filter dropdown menu to display:
• All events
• Information events only
• Error events only
Click the arrow on the Date/Time header to reverse the chronological order.
To save a copy of the Backup Event Log as a text file:
1. Go to the Main Window.
2. Click the SmartSYNC icon.
3. Click the Event Log button.
Note
For NAS system events, see “Viewing the System Event Log” on
page 143.

Promise Technology Smartstor NS4600 Specifications

General

RAID levels	0, 1, 5, 10
Storage drive size	3.5 \
Hot-swap drive bays	Yes
Storage drive capacity	0 GB
Supported file systems	EXT3, FAT32
Storage drive interface	Serial ATA II
Total installed storage capacity	0 TB
Number of storage drives installed	4
Internal memory	0.25 GB
Processor model	-
Processor frequency	0.6 GHz
Maximum data transfer rate	1000 Mbit/s
Supported network protocols	FTP, DHCP, NTP
Compliance industry standards	IEEE 802.3i, IEEE 802.3ab, IEEE 802.3u
Certification	RoHS, CE, FCC, UL, TUV
Data transfer rate	3 Gbit/s
Dimensions (WxDxH)	152.5 x 229.6 x 188.2 mm
Power requirements	100 - 230 V/50-60 Hz
Networking features	Gigabit Ethernet
Compatible operating systems	Windows 2000/XP/2003/Vista Mac x 10.4 + Linux
USB 2.0 ports quantity	2
Ethernet LAN (RJ-45) ports	1
Power supply unit (PSU) capacity	90 W
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Weight	2500 g
