SmartStor NS4600 Product Manual
214
4. Optional. Type a new Computer Description into the field provided. (F)
5. Optional. Click the Enable option button beside Recycle Bin. (G)
Enabled – Deleted files move the Recycle Bin. You must empty the
Recycle Bin to remove them from the SmarStor. Uses more space.
Disabled – Default. Deleted files are immediately removed from the
SmartStor. Saves space but has no chance of file recovery.
6. Choose the option button to make the SmartStor a member of: (H)
An Active Directory (AD) Domain
•A Workgroup
Note: If you join an AD Domain, you automatically disable your NIS Domain
settings. See “Setting up UNIX/Linux Access” on page 216.
7. Optional. If you chose an AD Domain, enter the following in the fields
provided: (H-1)
Domain or Workgroup Name. This name appears in the Windows
Network Neighborhood.
Domain Controller
Administrator Account
Administrator Password
See your Network Administrator for help with this information.
8. Optional. If you chose an Workgroup, enter the Workgroup name into the
field provided:(H-1)
This name appears in the Windows Network Neighborhood.
See your
Network Administrator for help with this information.
9. Click the OK button to save your settings. (I)
Setting up File Sharing
To set up Windows file sharing:
1. Click the Administration topic and choose the File & Print icon to expand
the Tree. (A)

Table of Contents

Other manuals for Promise Technology Smartstor NS4600

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Promise Technology Smartstor NS4600 and is the answer not in the manual?

Promise Technology Smartstor NS4600 Specifications

General IconGeneral
RAID levels0, 1, 5, 10
Storage drive size3.5 \
Hot-swap drive baysYes
Storage drive capacity0 GB
Supported file systemsEXT3, FAT32
Storage drive interfaceSerial ATA II
Total installed storage capacity0 TB
Number of storage drives installed4
Internal memory0.25 GB
Processor model-
Processor frequency0.6 GHz
Maximum data transfer rate1000 Mbit/s
Supported network protocolsFTP, DHCP, NTP
Compliance industry standardsIEEE 802.3i, IEEE 802.3ab, IEEE 802.3u
CertificationRoHS, CE, FCC, UL, TUV
Data transfer rate3 Gbit/s
Dimensions (WxDxH)152.5 x 229.6 x 188.2 mm
Power requirements100 - 230 V/50-60 Hz
Networking featuresGigabit Ethernet
Compatible operating systemsWindows 2000/XP/2003/Vista Mac x 10.4 + Linux
USB 2.0 ports quantity2
Ethernet LAN (RJ-45) ports1
Power supply unit (PSU) capacity90 W
Operating temperature (T-T)5 - 35 °C
Operating relative humidity (H-H)10 - 85 %
Weight and Dimensions IconWeight and Dimensions
Weight2500 g
