Promise Technology Smartstor NS4600 User Manual

Chapter 5: PASM
273
2. In the Tree, click the System Information icon.
3. Click the System Information tab.
4. Click the Locate button.
The SmartStor’s buzzer beeps three times and the system status LED blinks
RED three times (right).
Viewing System Information
To view system information:
1. Click the Administration topic and choose the System icon to expand the
Tree.
2. In the Tree, click the System Information icon.
3. Click the System Information tab.
System Information includes:
• Operating System – Embedded Linux
• Firmware Version – Changes when you upgrade the firmware. See
“Upgrading the Firmware” on page 337
• CPU model – MPC 8343
• Network Adapter – Gigabit Ethernet
• MAC Address – MAC address of the Ethernet card
• Network Flow – Inflow and Outflow speeds in bits per second
System Status LED

Promise Technology Smartstor NS4600 Specifications

General

RAID levels	0, 1, 5, 10
Storage drive size	3.5 \
Hot-swap drive bays	Yes
Storage drive capacity	0 GB
Supported file systems	EXT3, FAT32
Storage drive interface	Serial ATA II
Total installed storage capacity	0 TB
Number of storage drives installed	4
Internal memory	0.25 GB
Processor model	-
Processor frequency	0.6 GHz
Maximum data transfer rate	1000 Mbit/s
Supported network protocols	FTP, DHCP, NTP
Compliance industry standards	IEEE 802.3i, IEEE 802.3ab, IEEE 802.3u
Certification	RoHS, CE, FCC, UL, TUV
Data transfer rate	3 Gbit/s
Dimensions (WxDxH)	152.5 x 229.6 x 188.2 mm
Power requirements	100 - 230 V/50-60 Hz
Networking features	Gigabit Ethernet
Compatible operating systems	Windows 2000/XP/2003/Vista Mac x 10.4 + Linux
USB 2.0 ports quantity	2
Ethernet LAN (RJ-45) ports	1
Power supply unit (PSU) capacity	90 W
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Weight	2500 g
