SmartStor NS4600 Product Manual
238
You do NOT create a RAID Volume or folders with the USB drive or memory stick
as you would with the disk drives installed in the SmartStor enclosure.
With the USB drive or memory stick connected to the SmartStor, create a
network drive on your PC and choose the USB disk as the folder. Then you can
access the USB drive or memory stick from your PC.
See “Chapter 3: Connecting to the SmartStor” on page 31 for more information.
Formatting an External USB Drive or Memory Stick
This option only appears when SmartStor does not recognize the file system on
the USB drive or memory stick.
To format a USB drive or memory stick:
1. Attach the USB drive or memory stick to one of the USB ports on the back of
the SmartStor.
2. Click the Administration topic and choose the RAID & File System icon to
expand the Tree.
3. In the Tree, click the File System Management icon.
4. On the File System Status tab, highlight the USB drive.
5. From the Format File System Type dropdown menu, choose a file system:
• FAT 32 – Use for Windows, Linux, and Macs, and SmartStor
• Ext3 – Use for UNIX and Linux PCs, and SmartStor
6. Click the Format USB Disk button.
7. In the confirmation box, type YES, then click the OK button.
Formatting requires several minutes, depending on the size of your USB drive or
memory stick.
Viewing the iSCSI Status
The iSCSI Status screen allows you to set up the services setting and displays
information about the iSCSI on the SmartStor:
iSCSI (Internet Small Computer System Interface) is an Internet Protocol (IP)-
based storage networking standard for linking data storage facilities
To setup the iSCSI services settings:
1. Click the Administration topic and choose the RAID & File System icon to
expand the Tree.
Caution
When you format a USB drive or memory stick, you delete all the
data saved on it. Back up any important data before you format.

Promise Technology Smartstor NS4600 Specifications

General

RAID levels	0, 1, 5, 10
Storage drive size	3.5 \
Hot-swap drive bays	Yes
Storage drive capacity	0 GB
Supported file systems	EXT3, FAT32
Storage drive interface	Serial ATA II
Total installed storage capacity	0 TB
Number of storage drives installed	4
Internal memory	0.25 GB
Processor model	-
Processor frequency	0.6 GHz
Maximum data transfer rate	1000 Mbit/s
Supported network protocols	FTP, DHCP, NTP
Compliance industry standards	IEEE 802.3i, IEEE 802.3ab, IEEE 802.3u
Certification	RoHS, CE, FCC, UL, TUV
Data transfer rate	3 Gbit/s
Dimensions (WxDxH)	152.5 x 229.6 x 188.2 mm
Power requirements	100 - 230 V/50-60 Hz
Networking features	Gigabit Ethernet
Compatible operating systems	Windows 2000/XP/2003/Vista Mac x 10.4 + Linux
USB 2.0 ports quantity	2
Ethernet LAN (RJ-45) ports	1
Power supply unit (PSU) capacity	90 W
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Weight	2500 g
