SmartStor NS4600 Product Manual
318
If the Ethernet Activity LED is dark, see “Solving Network Connection
Problems” on page 316.
• Be sure that SmartNAVI is looking on the same network where you
connected the SmartStor.
• If you are running a personal firewall on your Windows PC, the firewall might
prevent you from accessing folders on the SmartStor. You must do one of the
following actions:
• Disable the firewall
• Add an exception for the SmartStor
See “Resolving a Windows Firewall Issue” on page 322.
Verifying Connections with SmartNAVI
If your PC has multiple network connections, you must
verify that SmartNAVI is looking on the network where the
SmartStor is installed:
Double-click the SmartNAVI icon in the Windows
application tray or Mac Dock (right).
The SmartNAVI Main Window opens.
SmartNAVI in
Windows
SmartNAVI in
Mac OS X

Promise Technology Smartstor NS4600 Specifications

General

RAID levels	0, 1, 5, 10
Storage drive size	3.5 \
Hot-swap drive bays	Yes
Storage drive capacity	0 GB
Supported file systems	EXT3, FAT32
Storage drive interface	Serial ATA II
Total installed storage capacity	0 TB
Number of storage drives installed	4
Internal memory	0.25 GB
Processor model	-
Processor frequency	0.6 GHz
Maximum data transfer rate	1000 Mbit/s
Supported network protocols	FTP, DHCP, NTP
Compliance industry standards	IEEE 802.3i, IEEE 802.3ab, IEEE 802.3u
Certification	RoHS, CE, FCC, UL, TUV
Data transfer rate	3 Gbit/s
Dimensions (WxDxH)	152.5 x 229.6 x 188.2 mm
Power requirements	100 - 230 V/50-60 Hz
Networking features	Gigabit Ethernet
Compatible operating systems	Windows 2000/XP/2003/Vista Mac x 10.4 + Linux
USB 2.0 ports quantity	2
Ethernet LAN (RJ-45) ports	1
Power supply unit (PSU) capacity	90 W
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Weight	2500 g
