SmartStor NS4600 Product Manual
342
5. Plug in the power cord.
6. Boot the SmartStor.
See “Connecting the Power” on page 10.
Replacing the Cooling Fan
The SmartStor NS4600 uses the following cooling fan.
• Make and model: NMB-MAT 3106KL-04W-B39-C50
• Dimensions: 80 x 80 x 15mm
• Input: 12V, 0.11A
• Output: 2200 RPM, 23.3 CFM, tachometer signal
A replacement fan might be noisier in operation if the fan lacks a tachometer
signal which SmartStor’s management software uses to monitor and control fan
speed.
Removing the Cooling Fan
To remove the old cooling fan:
1. Shut down the SmartStor.
See “Shutting Down the SmartStor” on page 30 or page 271.
2. Unplug the power cord.
Warning
The fan contains hazardous moving parts. Keep fingers and other
body parts away.
Important
If your SmartStor is still under warranty, contact Technical Support
for repair under RMA. See page 329.

Promise Technology Smartstor NS4600 Specifications

General

RAID levels	0, 1, 5, 10
Storage drive size	3.5 \
Hot-swap drive bays	Yes
Storage drive capacity	0 GB
Supported file systems	EXT3, FAT32
Storage drive interface	Serial ATA II
Total installed storage capacity	0 TB
Number of storage drives installed	4
Internal memory	0.25 GB
Processor model	-
Processor frequency	0.6 GHz
Maximum data transfer rate	1000 Mbit/s
Supported network protocols	FTP, DHCP, NTP
Compliance industry standards	IEEE 802.3i, IEEE 802.3ab, IEEE 802.3u
Certification	RoHS, CE, FCC, UL, TUV
Data transfer rate	3 Gbit/s
Dimensions (WxDxH)	152.5 x 229.6 x 188.2 mm
Power requirements	100 - 230 V/50-60 Hz
Networking features	Gigabit Ethernet
Compatible operating systems	Windows 2000/XP/2003/Vista Mac x 10.4 + Linux
USB 2.0 ports quantity	2
Ethernet LAN (RJ-45) ports	1
Power supply unit (PSU) capacity	90 W
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Weight	2500 g
