SmartStor NS4600 Product Manual
322
Figure 10.Reset button and System Status LED
Resolving a Windows Firewall Issue
If you a running a personal firewall on your Windows PC, the firewall might
prevent the you from accessing the SmartStor over your network.
Follow this procedure to add an exception for the SmartStor:
1. From the Windows Start menu, choose Settings, then Network Connections.
The Network Connections window opens.
2. Right-click Local Area Connection and choose Properties from the popup
menu.
The local Area Connection properties dialog box opens.
3. Click the Advanced tab.
Reset button
System Status LED
