SmartStor NS4600 Product Manual
338
When the installation is done, the SmartStor reboots automatically. When the
SmartStor beeps once, it is ready for use.
Error During Upgrade
If an error occurs during the firmware upgrade, the SmartStor cannot reboot in
mormal mode. You must boot the SmartStor in Safe Mode and repeat the
firmware installation. See “Booting the SmartStor in Safe Mode” below.
No Reboot After Upgrade
If the SmartStor has not rebooted after 20 minutes, there might be a service
conflict that prevented the reboot. You must hard boot the SmartStor manually.
See “Hard Booting the SmartStor” below.
Booting the SmartStor in Safe Mode
If an error occurs during firmware upgrade, the SmartStor will not reboot
normally. You must reboot the SmartStor in Safe Mode and repeat the firmware
upgrade
To boot the SmartStor in safe mode:
1. Press the Power button.
2. Immediately press the Power and Reset buttons at the same time.
See page 339, Figure 1.
It takes about a minute to boot the SmartStor. When fully booted:
• The System Status LED turns blue.
• The buzzer beeps one time.
At this point, the SmartStor is in Safe Mode.
3. Repeat the procedure under “Installing the Firmware Upgrade File” on
page 337.
Hard Booting the SmartStor
To hard reboot the SmartStor:
1. Disconnect the power cable from the SmartStor.
See page 339, Figure 1.
2. Wait 10 seconds, then reconnect the power cable.
3. Press the Power button.
Caution
Do not disconnect the power to reboot the SmartStor unless the
SmartStor failed to reboot itself after the firmware update.

Promise Technology Smartstor NS4600 Specifications

General

RAID levels	0, 1, 5, 10
Storage drive size	3.5 \
Hot-swap drive bays	Yes
Storage drive capacity	0 GB
Supported file systems	EXT3, FAT32
Storage drive interface	Serial ATA II
Total installed storage capacity	0 TB
Number of storage drives installed	4
Internal memory	0.25 GB
Processor model	-
Processor frequency	0.6 GHz
Maximum data transfer rate	1000 Mbit/s
Supported network protocols	FTP, DHCP, NTP
Compliance industry standards	IEEE 802.3i, IEEE 802.3ab, IEEE 802.3u
Certification	RoHS, CE, FCC, UL, TUV
Data transfer rate	3 Gbit/s
Dimensions (WxDxH)	152.5 x 229.6 x 188.2 mm
Power requirements	100 - 230 V/50-60 Hz
Networking features	Gigabit Ethernet
Compatible operating systems	Windows 2000/XP/2003/Vista Mac x 10.4 + Linux
USB 2.0 ports quantity	2
Ethernet LAN (RJ-45) ports	1
Power supply unit (PSU) capacity	90 W
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Weight	2500 g
