Appendix A: Maintenance
339
It takes about a minute to boot the SmartStor. When fully booted:
• The System Status LED turns blue.
• The buzzer beeps one time.
4. Verify that the SmartStor now appears in SmartNAVI Main window.
The SmartStor automatically runs a File System Check due to the abnormal
shutdown. During the File System Check, the System Status LED blinks
amber and the Disk Activity LEDs blink blue.
See “Checking File System Status in PASM” on page 310 for more
information.
Figure 1. SmartStor front and back views
System Status LED
Power Button
Power Connection
Disk Activity LED
Reset Button

Promise Technology Smartstor NS4600 Specifications

General

RAID levels	0, 1, 5, 10
Storage drive size	3.5 \
Hot-swap drive bays	Yes
Storage drive capacity	0 GB
Supported file systems	EXT3, FAT32
Storage drive interface	Serial ATA II
Total installed storage capacity	0 TB
Number of storage drives installed	4
Internal memory	0.25 GB
Processor model	-
Processor frequency	0.6 GHz
Maximum data transfer rate	1000 Mbit/s
Supported network protocols	FTP, DHCP, NTP
Compliance industry standards	IEEE 802.3i, IEEE 802.3ab, IEEE 802.3u
Certification	RoHS, CE, FCC, UL, TUV
Data transfer rate	3 Gbit/s
Dimensions (WxDxH)	152.5 x 229.6 x 188.2 mm
Power requirements	100 - 230 V/50-60 Hz
Networking features	Gigabit Ethernet
Compatible operating systems	Windows 2000/XP/2003/Vista Mac x 10.4 + Linux
USB 2.0 ports quantity	2
Ethernet LAN (RJ-45) ports	1
Power supply unit (PSU) capacity	90 W
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Weight	2500 g
