Chapter 3: Connecting to the SmartStor
59
The Main Window opens.
3. Click the NAS Management icon.
4. Click the Add Plugin button.
5. Do one of the following actions:
• Type the name of the plug-in file
• Click the folder icon, navigate to the Firefly plug-in file, click it, then click
the Open button
6. Click the OK button.
After a few moments, the plug-in is added.
7. Click the Configure Plugin button.
The newly added plug-in appears in the list. Its Service Status is OFF.
8. Click the plug-in to choose it.
The plug-in’s name turns red.
9. Click the Enable button.
Warning
Do not disconnect the power or shut down the SmartStor while the
plug-in installation is running!

Promise Technology Smartstor NS4600 Specifications

General

RAID levels	0, 1, 5, 10
Storage drive size	3.5 \
Hot-swap drive bays	Yes
Storage drive capacity	0 GB
Supported file systems	EXT3, FAT32
Storage drive interface	Serial ATA II
Total installed storage capacity	0 TB
Number of storage drives installed	4
Internal memory	0.25 GB
Processor model	-
Processor frequency	0.6 GHz
Maximum data transfer rate	1000 Mbit/s
Supported network protocols	FTP, DHCP, NTP
Compliance industry standards	IEEE 802.3i, IEEE 802.3ab, IEEE 802.3u
Certification	RoHS, CE, FCC, UL, TUV
Data transfer rate	3 Gbit/s
Dimensions (WxDxH)	152.5 x 229.6 x 188.2 mm
Power requirements	100 - 230 V/50-60 Hz
Networking features	Gigabit Ethernet
Compatible operating systems	Windows 2000/XP/2003/Vista Mac x 10.4 + Linux
USB 2.0 ports quantity	2
Ethernet LAN (RJ-45) ports	1
Power supply unit (PSU) capacity	90 W
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Weight	2500 g
