SmartStor NS4600 Product Manual
8
Figure 1. SmartStor NS4600 Front View
Figure 2. SmartStor NS4600 Rear View
Disk Drive
Drive Carrier
Disk Activity
LED
Ethernet
Activity LED
One Touch
Backup Button
Disk Status
LED
Note: This SmartStor is shown without the front door.
System Status
LED
Front Door
Lock
Power
Connection
USB
Connections
RJ45 Network
Connection
Disk Drive
Cooling Fan
Power
Button
eSATA
Connection
