Remote command:
CALCulate<n>:MARKer<m>:FUNCtion:POWer:PRESet on page 728
CP/ACLR Settings ← Ch Power ACLR
Opens a submenu to configure the channel power and adjacent channel power mea-
surement independently of the predefined standards (for details see also "Predefined
CP/ACLR Standards" on page 246 and "Optimized Settings for CP/ACLR Test Param-
eters" on page 247).
# of TX Chan ← CP/ACLR Settings ← Ch Power ACLR
Opens an edit dialog box to enter the number of carrier signals to be taken into
account in channel and adjacent-channel power measurements. Values from 1 to 18
are allowed.
Remote command:
[SENSe:]POWer:ACHannel:TXCHannel:COUNt on page 733
# of Adj Chan ← CP/ACLR Settings ← Ch Power ACLR
Opens an edit dialog box to enter the number of adjacent channels to be considered in
the adjacent-channel power measurement. Values from 0 to 12 are allowed.
The following measurements are performed depending on the number of the channels:
0 Only the channel powers are measured.
1 The channel powers and the power of the upper and lower adjacent channel are measured.
2 The channel powers, the power of the upper and lower adjacent channel, and of the next higher
and lower channel (alternate channel 1) are measured.
3 The channel power, the power of the upper and lower adjacent channel, the power of the next
higher and lower channel (alternate channel 1), and of the next but one higher and lower adja-
cent channel (alternate channel 2) are measured.
… …
12 The channel power, the power of the upper and lower adjacent channel, and the power of the all
higher and lower channels (alternate channel 1 to 11) are measured.
Remote command:
[SENSe:]POWer:ACHannel:ACPairs on page 730
Channel Setup ← CP/ACLR Settings ← Ch Power ACLR
Opens a dialog to define the channel settings for all channels, independant of the
defined number of used TX or adjacent channels.
