In the "Recall" dialog box, the items saved in the selected file are displayed.
Remote command:
MMEMory:SELect[:ITEM]:HWSettings on page 985
MMEMory:SELect[:ITEM]:LINes:ALL on page 985
MMEMory:SELect[:ITEM]:TRACe[:ACTive] on page 986
MMEMory:SELect[:ITEM]:TRANsducer:ALL on page 986
Enable all Items ← Select Items ← Save
Selects all items for saving or loading.
Remote command:
MMEMory:SELect[:ITEM]:ALL on page 985
Disable all Items ← Select Items ← Save
Selects none of the items for saving or loading.
Remote command:
MMEMory:SELect[:ITEM]:NONE on page 986
Delete File ← Save
Deletes the selected settings file.
Remote command:
MMEMory:CLEar:STATe 1, on page 946
Recall
Opens the "Recall" dialog box to load a settings file. To navigate in the dialog box, use
the corresponding softkeys.
For details see also Chapter 10.1.2, "File Selection Dialog Boxes", on page 536.
Path Directory from which the settings file is loaded. The default path for user
settings files is C:\r_s\instr\user
Files List of stored settings files
File Name Name of settings file
Comment Comment of the settings file
[Items] Items saved in the settings file
Note: After you use the "Recall" function, the history of previous actions is deleted, i.e.
any actions performed previously cannot be undone or redone using the [UNDO/
REDO] keys.
Remote command:
MMEMory:LOAD:STATe on page 947
Startup Recall
Opens a submenu to activate or deactivate and set up the startup recall function.
Saving and Recalling Settings Files – SAVE/RCL Key
