R&S ESR Series User Manual

Remote Control
R&S
®
ESR
693User Manual 1175.7068.02 ─ 12
CALCulate<n>:MARKer<m>:MAXimum:RIGHt
This command positions a marker to the next smaller trace maximum on the right of
the current value (i.e. in ascending X values).
If no next smaller maximum value is found on the trace (level spacing to adjacent val-
ues < peak excursion), an execution error (error code: -200) is produced.
Suffix:
<n>
.
Selects the measurement window.
<m> Selects the marker.
Example:
CALC:MARK2:MAX:RIGH
Positions marker 2 to the next lower maximum value to the right
of the current value.
Usage: Event
Manual operation: See "Next Mode" on page 205
CALCulate<n>:MARKer<m>:MINimum:LEFT
This command positions a marker to the next higher trace minimum on the left of the
current value (i.e. in descending X direction).
If no next higher minimum value is found on the trace (level spacing to adjacent values
< peak excursion), an execution error (error code: -200) is produced.
Suffix:
<n>
.
Selects the measurement window.
<m> Selects the marker.
Example:
CALC:MARK2:MIN
Positions marker 2 to the minimum value of the trace.
CALC:MARK2:MIN:LEFT
Positions marker 2 to the next higher minimum value to the left
of the current value.
Usage: Event
Manual operation: See "Next Mode" on page 205
CALCulate<n>:MARKer<m>:MINimum:NEXT
This command positions ae marker to the next higher trace minimum.
If no next higher minimum value is found on the trace (level spacing to adjacent values
< peak excursion), an execution error (error code: -200) is produced.
Suffix:
<n>
.
Selects the measurement window.
<m> Selects the marker.
Remote Commands in Receiver Mode
