R&S ESR Series User Manual

Remote Control
R&S
®
ESR
694User Manual 1175.7068.02 ─ 12
Example:
CALC:MARK2:MIN
Positions marker 2 to the minimum value of the trace.
CALC:MARK2:MIN:NEXT
Positions marker 2 to the next higher maximum value.
Usage: Event
Manual operation: See "Next Min" on page 205
See "Next Mode" on page 205
CALCulate<n>:MARKer<m>:MINimum[:PEAK]
This command positions the marker on the current trace minimum.
The corresponding marker is activated first or switched to marker mode, if necessary.
If no minimum value is found on the trace (level spacing to adjacent values < peak
excursion), an execution error (error code: -200) is produced.
Suffix:
<n>
.
Selects the measurement window.
<m> depends on mode
Selects the marker.
Example:
CALC:MARK2:MIN
Positions marker 2 to the minimum value of the trace.
Usage: Event
Manual operation: See "Min" on page 205
CALCulate<n>:MARKer<m>:MINimum:RIGHt
This command positions a marker to the next higher trace minimum on the right of the
current value (i.e. in ascending X direction).
If no next higher minimum value is found on the trace (level spacing to adjacent values
< peak excursion), an execution error (error code: -200) is produced.
Suffix:
<n>
.
Selects the measurement window.
<m> Selects the marker.
Example:
CALC:MARK2:MIN
Positions marker 2 to the minimum value of the trace.
CALC:MARK2:MIN:RIGH
Positions marker 2 to the next higher minimum value to the right
of the current value.
Usage: Event
Manual operation: See "Next Mode" on page 205
Remote Commands in Receiver Mode
