CALCulate<n>:MARKer<m>:FUNCtion:POWer:SELect <MeasType>
This command selects – and switches on – the specified power measurement type in
the window specified by the suffix <n>.
The channel spacings and channel bandwidths are configured in the SENSe:POWer
subsystem.
Note: If CPOWer is selected, the number of adjacent channels ( [SENSe:]POWer:
ACHannel:ACPairs) is set to 0. If ACPower is selected, the number of adjacent
channels is set to 1, unless adjacent-channel power measurement is switched on
already.
The channel/adjacent-channel power measurement is performed for the trace selected
with [SENSe:]POWer:TRACe.
The occupied bandwidth measurement is performed for the trace on which marker 1 is
positioned. To select another trace for the measurement, marker 1 is to be positioned
on the desired trace by means of CALCulate<n>:MARKer<m>:TRACe.
Suffix:
<n>
.
Selects the measurement window.
<m> Selects the marker.
Parameters:
<MeasType> ACPower | CPOWer | MCACpower | OBANdwidth | OBWidth |
CN | CNO
ACPower
Adjacent-channel power measurement with a single carrier sig-
nal
CPOWer
Channel power measurement with a single carrier signal (equiv-
alent to adjacent-channel power measurement with "NO. OF
ADJ CHAN" = 0)
MCACpower
Channel/adjacent-channel power measurement with several car-
rier signals
OBANdwidth | OBWidth
Measurement of occupied bandwidth
CN
Measurement of carrier-to-noise ratio
CN0
Measurement of carrier-to-noise ratio referenced to 1 Hz band-
width
Example:
CALC:MARK:FUNC:POW:SEL ACP
Switches on adjacent-channel power measurement.
