R&S ESR Series User Manual

Remote Control
R&S
®
ESR
724User Manual 1175.7068.02 ─ 12
CALCulate<n>:MARKer<m>:FUNCtion:POWer[:STATe] <State>
This command switches off the power measurement in the window specified by the
suffix <n>.
Suffix:
<n>
.
Selects the measurement window.
<m> Selects the marker.
Parameters:
<State> OFF
Example:
CALC:MARK:FUNC:POW OFF
Switches off the power measurement.
Usage: Event
Manual operation: See "Ch Power ACLR" on page 223
See "OBW (span > 0)" on page 223
See "Ch Power ACLR" on page 236
See "C/N" on page 251
See "C/No" on page 251
See "OBW" on page 254
CALCulate<n>:MARKer<m>:FUNCtion:POWer:MODE <Mode>
This commands defines the method by which the channel power values are calculated
from the current trace in the window specified by the suffix <n>.
Suffix:
<n>
.
Selects the measurement window.
<m> Selects the marker.
Parameters:
<Mode> WRITe | MAXHold
WRITe
The channel power and the adjacent channel powers are calcu-
lated directly from the current trace
MAXHold
The power values are calculated from the current trace and
compared with the previous power value using a maximum algo-
rithm.
Example:
CALC:MARK:FUNC:POW:MODE MAXH
Sets the Maxhold channel power mode.
Manual operation: See "Clear/Write" on page 242
See "Max Hold" on page 243
Remote Commands in Spectrum Analyzer Mode
