R&S ESR Series User Manual

Remote Control
R&S
®
ESR
769User Manual 1175.7068.02 ─ 12
[SENSe:]ESPectrum:RANGe<range>:LIMit<source>:STATe <State>
This command sets the type of limit check for all ranges.
Suffix:
<range>
.
irrelevant
Parameters:
<State> ABSolute | RELative | AND | OR
ABSolute
Checks only the absolute limits defined.
RELative
Checks only the relative limits. Relative limits are defined as rel-
ative to the measured power in the reference range.
AND
Combines the absolute and relative limit. The limit check fails
when both limits are violated.
OR
Combines the absolute and relative limit. The limit check fails
when one of the limits is violated.
*RST:
REL
Example:
ESP:RANG3:LIM:STAT AND
Sets for all ranges the combined absolute/relative limit check.
Manual operation: See "Limit Check 1-4" on page 261
[SENSe:]ESPectrum:RANGe<range>:RLEVel <Value>
This command sets the reference level for the specified range.
Note that this parameter can not be set for all ranges if "Fast SEM" mode is activated
(see [SENSe:]ESPectrum:HighSPeed on page 762).
Suffix:
<range>
.
1...20
range
Parameters:
<Value> Refer to the data sheet.
*RST: -20 dBm
Example:
ESP:RANG2:RLEV 0
Sets the reference level of range 2 to 0 dBm.
Manual operation: See "Ref. Level" on page 260
[SENSe:]ESPectrum:RANGe<range>:SWEep:TIME <SweepTime>
This command sets the sweep time for the specified range.
Remote Commands in Spectrum Analyzer Mode
