R&S ESR Series User Manual

Quick Start
R&S
®
ESR
81User Manual 1175.7068.02 ─ 12
you must first switch to the edit mode in order to make changes. A focused area in the
edit mode is marked with a dashed blue frame (see Figure 3-7).
Figure 3-6: Focused area
Figure 3-7: Focused area in edit mode
Edit mode
When using the touchscreen for focus changes, all focused areas are in the edit mode
automatically, if available. Otherwise, you must switch to edit mode manually.
Switching to edit mode
1. Press the [ENTER] key.
2. To quit the edit mode, press the [ESC] key.
Working in dialog boxes
●
To edit alphanumeric parameters, use the keypad or the on-screen keyboard. For
details see Chapter 3.4.3.1, "Entering Numeric Parameters", on page 78 and
Chapter 3.4.3.2, "Entering Alphanumeric Parameters", on page 78. If you edit
fields, the edit mode is activated automatically when you start typing.
●
To move the focus to the next interface element (e.g. field, option, list), press it on
the screen, or turn the rotary knob.
Basic Operations
