R&S ESR Series User Manual

Remote Control
R&S
®
ESR
904User Manual 1175.7068.02 ─ 12
Example: SOUR2:DM:STAT ON
Switches on the external I/Q modulation of the tracking genera-
tor for screen B.
Usage: SCPI confirmed
Manual operation: See "External I/Q" on page 479
See "Modulation OFF" on page 479
See "External IQ" on page 499
SOURce<n>:FM:DEViation <Frequency>
This command defines the maximum frequency deviation at 1 V input voltage at the
FM input of the tracking generator.
This command is available with a tracking generator (option R&S FSV-B9).
Suffix:
<n>
.
1...4
Selects the measurement window.
Parameters:
<Frequency> The possible value range is 100 Hz to 10 MHz in steps of 10 Hz.
Range: 100 Hz to 10 MHz
Increment: 10 Hz
*RST: 100 Hz
Example:
SOUR1:FM:DEV 1 MHz
Sets the maximum frequency deviation of the tracking generator
for screen A to 1 MHz.
Usage: SCPI confirmed
Manual operation: See "External FM" on page 479
SOURce<n>:FM:STATe <State>
This command turns external frequency modulation of the tracking generator on and
off.
External I/Q modulation is switched off, if active. This command is available with a
tracking generator (option R&S FSV-B9).
Suffix:
<n>
.
1...4
Selects the measurement window.
Parameters:
<State> ON | OFF
*RST: OFF
Example:
SOUR2:FM:STAT ON
Switches on the external frequency modulation of the tracking
generator for screen B.
Remote Commands to Control the Tracking Generator
