R&S ESR Series User Manual

Remote Control
R&S
®
ESR
905User Manual 1175.7068.02 ─ 12
Usage: SCPI confirmed
Manual operation: See "External FM" on page 479
See "Modulation OFF" on page 479
SOURce<n>:FREQuency:OFFSet <Offset>
This command defines a frequency offset of the tracking generator. Frequency-con-
verting DUTs can be measured with this setting.
External I/Q modulation is switched off, if active. This command is available with a
tracking generator (option R&S FSV-B9).
Suffix:
<n>
.
1...4
Selects the measurement window.
Parameters:
<Offset> Note that the values (start frequency – tracking frequency offset)
and (stop frequency – tracking frequency offset) are both > 1
kHz or both < –1 kHz.
Range: -200 MHz to 200 MHz
*RST: 0 Hz
Example:
SOUR:FREQ:OFFS 10MHz
Defines a frequency offset of the tracking generator of 10 MHz.
Usage: SCPI confirmed
Manual operation: See "Frequency Offset" on page 487
SOURce<n>:POWer[:LEVel][:IMMediate][:AMPLitude] <Level>
This command defines the output level of the tracking generator.
Parameters:
<Level> Ouput level in dBm. The level range is specified in the data
sheet.
*RST: -20 dBm
Example:
SOUR:POW -20dBm
Sets the tracking generator level to -20 dBm.
Usage: SCPI confirmed
Manual operation: See "Source Power" on page 477
See "Source Power" on page 486
SOURce<n>:POWer[:LEVel][:IMMediate]:OFFSet <Offset>
This command defines a level offset for the tracking generator level. Thus, for exam-
ple, attenuators or amplifiers at the output of the tracking generator can be taken into
account for the setting.
Remote Commands to Control the Tracking Generator
