R&S ESR Series User Manual

Remote Control
R&S
®
ESR
978User Manual 1175.7068.02 ─ 12
DISPlay:CMAP<item>:DEFault <Setting>
This command resets the screen colors of all display items to their default settings.
Suffix:
<item>
.
irrelevant
Parameters:
<Setting> 1 | 2
Default settings DEFault1 and DEFault2
Example:
DISP:CMAP:DEF2
Selects default setting 2 for setting the colors.
Usage: Event
SCPI confirmed
Manual operation: See "Select Screen Color Set" on page 521
See "Set to Default" on page 522
DISPlay:CMAP<item>:HSL
<ColorTable>
This command defines the color table of the instrument.
The set values are not changed by *RST.
Suffix:
<item>
.
Selects the display item. For more information see Table 11-26.
Parameters:
<ColorTable> hue | sat | lum
hue
TINT
sat
SATURATION
lum
BRIGHTNESS
The value range is 0 to 1 for all parameters.
Example:
DISP:CMAP2:HSL 0.3,0.8,1.0
Changes the grid color.
Usage: SCPI confirmed
Manual operation: See "Screen Colors" on page 521
See "Select Object" on page 522
See "User Defined Colors" on page 522
DISPlay:CMAP<item>:PDEFined <Color>
This command defines the color table of the instrument using predefined color values.
Each suffix of CMAP is assigned to one or several graphical elements which can be
modified by varying the corresponding color setting.
Display Configuration
