R&S ESR Series User Manual

Remote Control
R&S
®
ESR
979User Manual 1175.7068.02 ─ 12
The values set are not changed by *RST.
Suffix:
<item>
.
Selects the display item. For more information see Table 11-26.
Parameters:
<Color> BLACk | BLUE | BROWn | GREen | CYAN | RED | MAGenta |
YELLow | WHITe | DGRAy | LGRAy | LBLUe | LGREen | LCYan |
LRED | LMAGenta
Example:
DISP:CMAP2:PDEF GRE
Usage: SCPI confirmed
Manual operation: See "Predefined Colors" on page 522
DISPlay:FORMat
<Format>
This command switches the measurement result display between FULL SCREEN and
SPLIT SCREEN.
Parameters:
<Format> SINGle | SPLit
SPLit
Show 2 or more screens on the display
SINGle
Show only 1 screen on the display
*RST: SPL
Example:
DISP:FORM SING
DISPlay:LOGO <State>
This command switches the company logo on the screen on or off.
Parameters:
<State> ON | OFF
*RST: ON
Example:
DISP:LOGO OFF
Manual operation: See "Print Logo (On/Off)" on page 521
DISPlay:PSAVe:HOLDoff <Minutes>
This command sets the holdoff time for the power-save mode of the display. The avail-
able value range is 1 to 60 minutes, the resolution 1 minute. The entry is dimension-
less.
Parameters:
<Minutes> 1 to 60
*RST: 15
Display Configuration
