Reflex Servitec 60 Original Operating Manual

Operation
38 — English
Vacuum spray degassing — 24.04.2020 - Rev. A
ER
Code
Alarm
Floating
contact
Cause
Remedy
Alarm
reset
11
Back-up volume
-
"With water meter" must be activated in the
Customer menu.
• Set value exceeded.
• Severe water loss in the system.
• Check set value in the Customer or Service
menu.
• Check the water loss and correct, if necessary.
Quit
12
Filling time
-
Set value for the maximum filling duration has
been exceeded
• Check set value in the Customer or Service
menu.
• Check the water loss and correct, if necessary.
Quit
13
Filling volume
-
Set value exceeded.
• Check set value in the Customer or Service
menu.
• Check the water loss and correct, if necessary.
Quit
14
Discharge period
-
• Set value exceeded.
• "DC" degassing line closed.
• Dirt trap clogged.
• Check set value in the Customer or Service
menu.
• Open the degassing pipe.
• Clean the dirt trap.
Quit
15
Make-up valve
-
Contact water meter measures without make-
up request.
Check the 2-way motorized ball valve (WV) for
leaks.
Quit
16
Power failure
-
No power.
Connect to power supply.
-
19
Stop ˃ 4 hours
-
Device is in stop mode for more than 4 hours.
Set the controller to Automatic mode.
-
20
Maximum make-up
quantity
-
Set value exceeded.
Reset the "Make-up quantity" meter in the
Customer menu.
Quit
21
Maintenance
recommended
-
Set value exceeded.
Carry out maintenance.
Quit
24
Water treatment
-
• Set value for soft water capacity
exceeded.
• Time interval for replacement of the
cartridge exceeded.
Replace the softening cartridges.
-
26
Conductivity measurement
-
Measured value outside the measuring range.
• Check set value in the Customer or Service
menu.
• Check the sensor and cabling.
-
27
Conductivity exceeded
-
• Set value exceeded.
• Cartridge capacity expired.
• Check set value in the Customer or Service
menu.
• Replace cartridge.
-
30
I/O module fault
-
• I/O module defective.
• Connection between option card and
controller faulty.
• Option card defective.
• Replace the I/O module.
• Check the connection between option card
and controller.
• Replace the option card.
-
31
EEPROM defective
Yes
• EEPROM defective.
• Internal calculation error.
Inform Reflex Customer Service.
-
32
Undervoltage
Yes
Supply voltage not achieved.
Check power supply.
-
33
Adjustment parameter
-
EPROM parameter memory defective.
Inform Reflex Customer Service.
Quit
34
Main board communication
faulty
-
• Connecting cable defective.
• Main board defective.
Inform Reflex Customer Service.
Quit
35
Digital input voltage faulty
-
Short-circuit of input voltage.
Check the wiring at the digital inputs (water meter,
for example).
-
36
Analogue input voltage
faulty
-
Short-circuit of input voltage.
Check the wiring at the analogue inputs
(pressure/conductivity).
-
37
Input voltage MKH1
-
Short-circuit of input voltage.
Check the wiring of the 2-way motorized ball valve.
-
