Section05FUELSYSTEM

Subsection 01 (CARBURETOR)

CARBURETOR

SERVICE TOOLS

Description Part Number Page

digital inductive type tachometer .........................................

529 014 500 ...........................................94

pump gauge tester ...............................................................

295 000 114

............................... 88–89, 91

SERVICE PRODUCTS

Description Part Number Page

Bombardier Lube.................................................................. 293 600 016 ..................................... 92–93

Loctite 243 (blue)..................................................................

293 800 060 ...........................................90

synthetic grease ...................................................................

293 550 010 ...........................................92

smr2005-052 85
