Section 01 MAINTENANCE
Subsection 03 (STORAGE PROCEDURES)
PROPULSION SYSTEM
Jet Pump
Lubricant in impeller shaft reservoir should be
drained. Reservoir should be cleaned and refilled
with jet pump synthetic oil (P/N 293 600 011).
Refer to JET PUMP for proper procedure.
CAUTION: Use only jet pump oil or equiva-
lent synthetic gear oil, otherwise component
service life could be reduced. Do not mix oil
brands or types.
PTO Flywheel
All Models Except 3D RFI
Remove PTO flywheel guard.
Lubricate PTO flywheel at grease fitting with syn-
thetic grease (P/N 293 550 010).
CAUTION: Do not lubricate excessively. Imme-
diately stop when a slight movement is noticed
on rubber boot.
F01I0BA
1
1. Grease PTO flywheel
CAUTION: Never leave any clothing, tool or
other objects near PTO flywheel and drive
shaft.
Seal Carrier
3D RFI Models
Remove rear access cover.
Lubricate seal carrier of drive shaft support with
synthetic grease (P/N 293 550 010). Stop lubricat-
ing when grease is just coming out of seal.
F22J05A
1
1. Grease seal carrier
ENGINE AND EXHAUST SYSTEM
Engine Draining
Check engine drain hose (lowest hose of engine).
Make sure there is no sand or other particles in it
and that it is not obstructed so that water can exit
the engine. Clean hose and fitting as necessary.
CAUTION: Water in engine drain hose must
be free to flow out, otherwise water could be
trapped in engine. Should water freeze in en-
gine, severe damage will occur. Check engine
drain hose for obstructions.
F07E0MA
1
TYPICAL
1. Engine drain hose
8 smr2005-044
