Section 06 ENGINE MANAGEMENT (RFI)
Subsection 02 (DIAGNOSTIC PROCEDURES)
POSSIBLE CAUSES ACTION
Sensor has been replaced
and TPS closed position
not reset.
• Reset
Closed
Throttle
.
Throttle body has been
replaced and TPS closed
position not reset.
• Reset
Closed
Throttle
.
ECM has been replaced
and TPS closed position
not reset.
• Reset
Closed
Throttle
.
Throttle cable too tight.
• Fix and reset
Closed
Throttle
.
Sensor is loose.
• Fix and reset
Closed
Throttle
.
Throttle bracket is loose.
• Fix and reset
Closed
Throttle
.
Adjustment screw worn
or loose.
• Change throttle
body.
Burnt Fuse and Related Fault Code
FUSE
NO
FUSE CAPACITY AND
FUNCTION
CODE
Main
5A
Accessories
None
1
10 A
Fuel pump
None
2
5A
RAVE solenoid
P-0231
3
10 A
Ignition coil and starter
solenoid
P-0079
4
3A
Injector 1 (MAG)
P-0616, P0351,
P-0352
5
3A
Injector 2 (PTO)
P-261, P-262
6 N P-264, P-265
NOTE: Fuses are located on the vehicle control
module (VCM). Refer to OVERVIEW for more de-
tails.
118 smr2005-055
