Section 06 ENGINE MANAGEMENT (RFI)
Subsection 02 (DIAGNOSTIC PROCEDURES)
COMMENT
NORMAL OPERATION RESUMES WHEN...
ENGINE SPEED LIMITATION
DETECTED WHEN ENGINE RUNS
DETECTED WHEN ENGINE STOPPED
CHECK ENGINE LIGHT
BEEPER CODE
DESCRIPTION
CODE
P-0261
Inj #1 short-circuit to ground
or open circuit
15
Y N Y (3200)
When the fault is
recovered
3200 because the engine
runs on 1 cylinder only
P-0262 Inj # 1 short-circuit to 12 V 15 Y N Y (3200)
When the fault is
recovered
3201 because the engine
runs on 1 cylinder only
P-0264
Inj #2 short-circuit to ground
or open circuit
15
Y N Y (3200)
When the fault is
recovered
3202 because the engine
runs on 1 cylinder only
P-0265 Inj#2short-circuitto12V 15 Y N Y (3200)
When the fault is
recovered
3203 because the engine
runs on 1 cylinder only
P-0336
Engine speed > [rpm]
detected
15
Y N
P-0351
Ignition coil 1 open circuit or
shortedtogroundorto12V
15
Y N Y N
When engine
stop
P-0352
Ignition coil 2 open circuit or
shortedtogroundorto12V
15 Y N Y N
When engine
stop
P-0513 DESS incorrect key
15
N Y N/A N/A N/A
P-0562 Battery voltage too low 15 N N Y 0
When the fault is
recovered
At 10 V
P-0563 Battery voltage too high
15
N N Y 5128
When the fault is
recovered
At 18 V
P-0601
TPS learns unlikely or
checksum fault
15
Y
P-0601 Module call monitoring 15 Y
P-0602 ECM not coded
15
Y
P-0604 RAM faulty 15 Y
P-0605 EPROM faulty
15
Y
P-0605
Checksum fault EEPROM
15 Y
P-0605 Coding ID checksum fault
15
Y
P-0605
Coding checksum fault
15 Y
P-0605 Programming checksum fault
15
Y
P-0608
Sensor 5 V power supply
short to gnd
15
Y Y Y N
When the key is
removed
Starter relay shorted to ground
5
N(1) Y N
When the fault is
recovered
P-0616
Starter relay open circuit
5
Y Y N
When the key is
removed
P-0617
Starterrelayshortedto12V
5 N
Y
(2)
N N
When the fault is
recovered
P-0650
Check engine circuit open
circuit or shorted to ground
5 N Y Y N
When the fault is
recovered
3D Series and GTI LE RFI
only
120 smr2005-055
