SeaDoo 3D User Manual

INTRODUCTION
Subsection 04 (MAGNETO SYSTEM)
30
F01D4WS
Loctite
243
Loctite
243
Loctite
243
Loctite
243
Loctite
243
Loctite
648
145 Nm
(107 lbfft)
Anti-seize
lubricant
Page heading
indicates section
and subsection
detailed.
Exploded view
assists you in
identifying parts and
related positions.
TYPICAL PAGE
F01A0CT
Illustration number
for publishing
process.
Subsection title
indicates
beginning of the
subsection.
Dotted box
contains parts of
a particular
model or an
exploded view.
Page number
Italic sub-title
above exploded
view indicate
pertaining models.
Drop represents
a liquid product
to be applied to a
surface. In this case
Loctite 243 to
screw threads.
Bold face number
indicates special
procedure
concerning this part.
smr2005-041 XI
www.SeaDooManuals.net

SeaDoo 3D Specifications

General

Manufacturer	Sea-Doo
Model	3D
Engine	Rotax 947
Horsepower	130 hp
Category	Personal Watercraft
Engine Type	2-stroke
Width	46.5 inches
Seating Capacity	1 person
