Section01MAINTENANCE
Subsection 03 (STORAGE PROCEDURES)
F15E03A
1
1. Hose pincher below T-fitting
Reconnect hose to T-fitting and remove hose
pincher.
Remove remaining hose pinchers.
Most of the antifreeze will drain out when remov-
ing the hose pinchers. Use a container to recover
it. DISPOSE ANTIFREEZE AS PER YOUR LOCAL
LAWS AND REGULATIONS.
NOTE: Although antifreeze will mainly drain out,
the antifreeze has mixed with the water that was
possibly trapped in the water jackets and thus pre-
venting freezing problems.
At preseason preparation, drain the remaining an-
tifreeze from cooling system prior to using the wa-
tercraft. Ensure no hose pincher was forgotten at
storage.
3D Series
Remove rear access panel and engine cover. Lock
steering pole in upright position with the holder.
WARNING
Always install steering pole holder while
working in the engine compartment.
Using a small hose pincher (P/N 295 000 076),
block heat exchange drain hose and cylinder drain
hose.
F22E03A
2
1
1. Pinch engine cylinder drain hose
2. Pinch engine heat exchanger drain hose
Install a large hose pincher (P/N 529 032 500) on
water outlet hose.
smr2005-044-002_A
1. Water outlet hose
Disconnect the water supply hose from cylinder
head.
smr2005-044 15
