Section 12 TECHNICAL SPECIFICATIONS
Subsection 01 (GTI MODELS)
PROPULSION GTI
Propulsion system BOMBARDIER Formula Pump
Jet pump type Axial flow single stage
Impeller rotation (seen from rear)
Counterclockwise
Transmission Direct drive
Coupling type Crowned splines
Oil type XP-S™ synthetic jet pump oil or SAE 75W90 GL5
Steering nozzle pivoting angle 20°
Minimum required water level 90 cm (35 in)
Drive shaft deflection (maximum) 0.5 mm (.020 in)
Impeller outside diameter 155.3 mm (6.114 in)
New 0.0 - 0.4 mm (.000 - .016 in)
Impeller/wear ring clearance
Wear limit 1.00 mm (.040 in)
Impeller shaft end play (new) 0
Impeller shaft radial play 0.05 mm (.002 in)
Impeller pitch/material Progressive pitch 10°-20°/stainless steel
ADDITIONAL INFORMATION: Do not mix different brands or oil types.
DIMENSIONS GTI
Number of passenger (driver included) 3
Overall length 307 cm (121 in)
Overall width 120 cm (47 in)
Overall height
104 cm (41 in)
Dry weight 274 kg (604 lb)
Load limit passenger and 10 kg (22 luggage) 243 kg (536 lb)
ADDITIONAL INFORMATION:
CAPACITIES GTI
Fuel tank (including reserve) 56.5 L (15 U.S. gal)
Fuel tank reserve
11.4L(3U.S.gal)
Oil injection reservoir 6 L (1.6 U.S. gal)
Capacity 100 mL (3.38 U.S. oz)Jet pump impeller shaft
reservoir
Oil level height
Up to plug
ADDITIONAL INFORMATION:
MATERIALS GTI
Hull
Composite
Inlet grate Aluminum
Impeller housing/stator/venturi/nozzle Plastic/plastic/aluminum/aluminum
Air intake silencer Thermoplastic
Flame arrester Multi-layer wire screen
Steering padding Thermoplastic
Fuel tank Polyethylene
Oil injection reservoir
Polyethylene
Seat
Polyurethane foam
ADDITIONAL INFORMATION:
PERFORMANCE GTI
Estimated pump power 34.8 kW (46.7 HP)
Maximum fuel consumption at wide open throttle
33.5 L/h (8.8 U.S. gal/h)
Fuel tank without reserve 1.21 hour
Cruising time at full throttle
Fuel tank reserve 21 minutes
ADDITIONAL INFORMATION:
354 smr2005-070
