Section 12 TECHNICAL SPECIFICATIONS
Subsection 03 (3D RFI MODEL)
PROPULSION 3D RFI 3D RFI PREMIUM
Propulsion system BOMBARDIER Formula pump
Jet pump type Axial flow single stage
Impeller rotation (seen from rear)
Counterclockwise
Transmission Direct drive
Coupling type Rubber coupling, split FR & RR
Oil type XP-S™ synthetic jet pump oil or SAE 75W90 GL5
Steering nozzle pivoting angle 20°
VTSnozzlepivotingangle ±4.3° ±9°
Minimum required water level 90 cm (35 in)
Drive shaft deflection (maximum) 0.5 mm (.020 in)
Impeller outside diameter 155.0 mm (6.102 in)
New 0.0 - 0.4 mm (.000 - .016 in)
Impeller/wear ring
clearance
Wear limit 1.0 mm (.040 in)
Impeller shaft end play (new) 0
Impeller shaft side play 0.05 mm (.002 in)
Impeller pitch/material Progressive pitch 11° -20°/stainless steel
ADDITIONAL INFORMATION: Do not mix different brands or oil types.
DIMENSIONS 3D RFI 3D RFI PREMIUM
Number of passenger (driver incl.)
1
Overall length 272 cm (107 in)
Overall width
112 cm (44 in)
Overall height
Vert: 92 cm (36.25 in)
Moto: 112 cm (44.25 in)
Kart: 96 cm (37.75 in)
Dry weight
Vert: 257 kg (565 lb)
Moto: 266 kg (585 lb)
Kart: 273 kg (600 lb)
Load limit (passenger and luggage) 10 kg (22 lb) 114 kg (250 lb)
ADDITIONAL INFORMATION:
CAPACITIES 3D RFI 3D RFI PREMIUM
Fuel tank (including reserve)
35 L (9.2 U.S. gal)
Fuel tank reserve (from low level signal) 5L(1.3U.S.gal)
Oil injection reservoir 4L(1.0U.S.gal)
Capacity 100 mL (3.4 U.S. oz)Jet pump impeller shaft
reservoir
Oil level height
Up to plug
ADDITIONAL INFORMATION:
MATERIALS 3D RFI 3D RFI PREMIUM
Hull Composite
Inlet grate Aluminum
Impeller housing/stator/venturi/nozzle Plastic/plastic/aluminum/aluminum
Air intake silencer Thermoplastic
Flame arrester Multi-layer wire screen
Steering padding
Thermoplastic
Fuel tank Polyethylene
Oil injection reservoir Polyethylene
Seat
Polyurethane foam
ADDITIONAL INFORMATION:
358 smr2005-070
