Section 03 ENGINE SYSTEM

Subsection 01 (AIR INTAKE SYSTEM)

717 Engines

F02F2CT

10 Nm

(89 lbfin)

10 Nm

(89 lbfin)

10 Nm

(89 lbfin)

Loctite 518

Loctite

243

Loctite 243

Loctite

243

Loctite

243

Loctite

243

4.5 Nm

(40 lbfin)

20 Nm

(15 lbfft)

38 smr2005-047
