SeaDoo 3D - Page 68

Section 03 ENGINE SYSTEM
Subsection 02 (EXHAUST SYSTEM)
F15D06S
26 Nm (19 lbfft)
NOTE: Press the pipe support on the engine
before torquing the pipe support bolts.
26 Nm
(19 lbfft)
1 Nm
(9 lbfin)
40 Nm
(30 lbfft)
40 Nm
(30 lbfft)
6 Nm
(53 lbfin)
48 Nm
(35 lbfft)
7
3
9
5
6 Nm
(53 lbfin)
48 Nm
(35 lbfft)
4
8
2
6
26 Nm
(19 lbfft)
26 Nm
(19 lbfft)
13
12
10
11
1
15
14
