Shihlin electric SE3 Series User Manual

Analog input and output parameter group 02
PARAMETER DESCRIPTION 99
5.3.4 Auxiliary frequency
 Frequency can be adjusted and synthesized flexibly to meet the different control requirements in different
scenarios.
Parameter
Name
Default
Setting Range
Content
02-07
P.240
Auxiliary frequency
0
0
Off
1
Output frequency = basic frequency + auxiliary frequency
(given by terminal 2-5)
2
Output frequency = basic frequency + auxiliary frequency
(given by terminal 4-5)
3
Output frequency = basic frequency - auxiliary frequency
(given by terminal 2-5)
4
Output frequency = basic frequency - auxiliary frequency
(given by 4-5 terminal)
5
Output frequency = proportional linkage signal (given by
terminal 2-5)
6
Output frequency = proportional linkage signal (given by
terminal 4-5)
Auxiliary frequency

When output frequency is lower than 01-01(P.2),it equals to lower limit frequency 01-01(P.2).
When output frequency is higher than 01-00(P.1), it equals to upper limit frequency 01-00(P.1).
5.3.5 Terminal 2-5 signal selection and processing
 Choose terminal 2-5 signal specifications, frequency compensation function, and signal polarity .etc.
Parameter
Name
Default
Setting Range
Content
02-08
P.73
Terminal 2-5 signal
range selection
1
0
0: Signal sampling range from 0 ~5V.
1
1: Signal sampling range from 0 ~10V.
2
2: Signal sampling range from 0 ~ -5V.
3
3: Signal sampling range from 0 ~ -10V.
4
4: Signal sampling range from -5～+5V.
5
5: Signal sampling range from -10～+10V.
Note: 1.Basic frequency command is given by keypad, communication or multi-speed terminal.
2. For proportional linkage signals, please refer to the description of parameter 02-06(P.185).
3. When use terminal 4-5 analog (voltage/current) signal as proportional linkage signal input terminal, please
refer to parameter 02-20(P.17); for the setting of external analog signal frequency range, please refer to
parameter 02-09(P.38)，02-21(P.39)，02-20(P.17)，02-08(P.73).
