6.2 Ways to measure voltage, current, power on main circuit
6.2.1 Measurement instruments choosing
 Since inverter voltage and current on input side and output side includes harmonics, measurement data result may
vary. Choose the instruments below (with commercial power supply) for measurement.
Voltage(V)
Current(A)
Power(kW)
Input side(R/L1, S/L2, T/L3)
Moving-iron type
Moving-iron type
Electrodynamic type
DC side(+/P, -/N)
Moving-coil type
---
---
Output side(U/T1, V/T2, W/T3)
Rectifier type
Moving-iron type
Electrodynamic type
Note: 1. Please pay attention to the instrument range and polarity;
2. Please pay attention to personal and property safety.
6.2.2 Measurement of voltages
 Inverter input side
Input side voltage has a sine wave and with extremely small distortion, accurate measurement can be made with
an ordinary AC meter.
 Inverter output side
Since the output side voltage has a PWM-controlled rectangular wave, always use a rectifier type voltmeter.
A pointer type meter cannot be used to measure the output side voltage as it indicates a value much greater than
the actual value.
A moving-iron type meter indicates an effective value which includes harmonics and therefore the value is larger
than that of the fundamental wave.
The value monitored on keypad is the inverter-controlled voltage itself. Hence, that value is accurate and it is
recommended to monitor values (analog output) using keypad.
6.2.3 Measurement of currents
 Use moving-iron type meters on both the input and output sides of inverter. However, if the carrier frequency
exceeds 5kHz, do not use this type of meter since an overcurrent losses produced in the internal metal parts of the
meter will increase and may burn. In this case, use an approximate-effective value type.
 Since current on the inverter input side tends to be inbalanced, measure three phases together is recommended.
Correct value cannot be obtained by measuring only one or two phases. On the other hand, the unbalanced ratio
of each phase of the output side current should be within 10%.
 When a clamp ammeter is used, always use an effective value detection type. A mean value detection type
produces a large error and may indicate an extremely smaller value than the actual value. The value monitored
on keypad is accurate if the output frequency varies, and it is recommended to monitor values (provide analog
output) using the keypad.
