Shihlin electric SE3 Series User Manual

Motor parameter group 05
PARAMETER DESCRIPTION 146
Note: 1. Before executing the IM motor inertia automatic measurement function, please follow 5.6.1 to perform the IM
motor parameter automatic measurement function first, please set 00-21(P.300) = 4.
2. Before executing the PM motor inertia automatic measurement function, please perform the PM motor
parameter automatic measurement function and Z-phase position automatic measurement function according
to 5.6.1. Please set 00-21(P.300) = 5.
3. Before executing the automatic inertia measurement function, please set a reasonable value of 05-17(P.318)
according to the inertia of the motor.
4. If the inertia measurement is abnormal, please adjust the value of 05-19(P.391) ~ 05-21(P.393) appropriately.
5.6.4 Second motor parameter
 By setting second motor parameter and matching digital input terminal, automatic measurement function of
second motor parameters can be performed.
Parameter
Name
Default
Setting Range
Content
05-22
P.332
Second motor rated
power
99999
0～650.00kW
---
99999
Off.
05-23
P.333
Second motor poles
99999
0～48
---
99999
Off.
05-24
P.334
Second motor rated
voltage
99999
0～510V
440 Voltage
0~255V
220 Voltage
99999
Off.
05-25
P.335
Second motor rated
frequency
99999
0～650.00Hz
---
99999
Off.
05-26
P.336
Second motor rated
current
99999
0~500.00A
---
99999
Off.
05-27
P.337
Second motor rated
rotation speed
99999
0～65000r/min
---
99999
Off.
05-28
P.338
Second motor
excitation current
99999
0~500.00A
---
99999
Off.
05-29
P.339
Second motor
(IM)stator resistance
99999
0～65000mΩ
---
99999
Off.
05-30
P.340
Second motor
(IM)rotor resistance
99999
0～65000mΩ
---
99999
Off.
05-31
P.341
Second motor
(IM)leakage
inductance
99999
0～6500.0mH
---
99999
Off.
05-32
P.342
Second motor
(IM)mutual inductance
99999
0～6500.0mH
---
99999
Off.
05-33
P.343
Second motor (PM)
stator resistance
99999
0～65000mΩ:
22K and below
99999
Off.
05-34
P.344
Second motor (PM)
d-axis inductance
99999
0～650.00mH
According to kW
99999
Off.
05-35
P.345
Second motor (PM)
q-axis inductance
99999
0～650.00mH
According to kW
99999
Off.
