Basic parameter group 01
PARAMETER DESCRIPTION 88
5.2.10 Second function
When given RT signal, these parameters will work.
01-08(P.21)=0/
01-08(P.21)=1
Second function
When 01-08
(P.21)
=0, minimum acceleration / deceleration time (01-22(P.44), 01-23(P.45) ) increment is 0.01s.
When 01-08
(P.21)
=1, minimum acceleration / deceleration time (01-22(P.44), 01-23(P.45)) increment is 0.1s.
When RT is “on”, second function is valid. For the motor operation characteristics, please refer to the following
second function setting.
If 01-22(P.44)≠99999 and 01-23(P.45)=99999, when RT is “on”, acceleration /deceleration time is the “set value of
01-22(P.44)”.
If 01-22(P.44)≠99999 and 01-24(P.46)=99999, when RT is “on”, torque boost is the “set value of 01-10(P.0)”.
If 01-22(P.44)≠99999 and 01-24(P.46)≠99999, when RT is “on”, torque boost is the “set value of 01-24(P.46)”.
If 01-22(P.44)≠99999 and 01-25(P.47)=99999, when RT is “on”, base frequency is the “set value of 01-03(P.3)”.
If 01-22(P.44)≠99999 and 01-25(P.47)≠99999, when RT is “on”, base frequency is the “set value of 01-25(P.47)”.
Note: RT mentioned here is the function name of “multi-function digital input terminal”. Please refer to
03-00~03-05(P.80~P.84、P.86) for function selection of multi-function digital input terminal; please refer to
Section 3.5 for related wiring.
5.2.11 Middle frequency, output voltage of middle frequency
Parameters can be set when using special motors, especially to adjust motor torque.
Output voltage 1 of
middle frequency
