PG feedback parameter group 09
PARAMETER DESCRIPTION 203
PG302Lhardware disconnection detection function （09-16(P.386) one-digit）effective to PM/IM motors，A1/B1
phase sequence detection function（09-16(P.386) two digits）only effective to IM motor
5.10.4 PG2 parameter
It is used to select the input mode of PG2 encoder.
Setting of A2/B2 encoder information connected to PG03.
A/Phase B pulse wave，forward spin when phase A is over
phase B for 90 degrees.
A/Phase B pulse wave，forward spin when phase B is over
phase A for 90 degrees.
Phase A :pulse wave，Phase B:directional sign，L:reverse
spin，H:forward spin
Phase A :pulse wave，Phase B: directional sign，L:forward
spin，H:reverse spin
PG2 parameter
When using PG card，09-06(P.355) is used for the setting of the number of pulse generated by the encoder per
revolution，i.e.,the number of pulse generated by phase A/B per cycle.
Parameter 09-07(P.356) is used for the setting of encoder input type.Please refer to parameter 09-02(P.351) for
encoder input type.
In speed mode，when 09-07(P.356) is not 0，the input pulse of A2/B2 acts as the frequency command (target
frequency(0.01Hz)=pulse frequency(Hz) /09-06(P.355)*09-10(P.359))；After activating inverter，the actual rotate
direction of the motor is determined by 09-07(P.356)、forward/reverse spin command and A2\B2 phase.
In position mode，when 09-07(P.356) is not zero，the input pulse of A2/B2 acts as the position command (target
position=A2B2 pulse number*09-10(P.359))；After activating inverter，the actual spin direction of the motor is
determined by 09-07(P.356)、forward/reverse spin command and A2\B2 phase.
When the frequency command and position command is coming from the input pulse of A2/B2，the rotate direction is as
follow：
