Analog input and output parameter group 02
PARAMETER DESCRIPTION 109
5.3.9 Terminal FM analog output function selection
 Selects monitor item output by terminal FM, when terminal HDO output function is FM.
Parameter
Name
Default
Setting Range
Content
02-44
P.543
Termianl FM output
function selection
0
0
Output frequency, use 02-51 (P.55) value as 100%.
1
Output current, use 02-52 (P.56) value as 100%.
2
Output DC bus voltage, use the OV trigger voltage as 100%.
3
Output inverter temperature accumulate rising rate, use NTC
trigger level as 100%.
4
Output inverter thermal relay accumulate rate, use the digital
thermal relay trigger level ( 06-00 ( P.9 ) ≠ 0 ) or the thermal
relay on IGBT trigger level ( 06-00 (P.9) = 0) as 100%.
5
Target frequency, use 02-51(P.55) value as 100%.
6
Fixed output, voltage or current output level can be set by
02-54 (P.541)
7
Output voltage, use inverter rated voltage as 100%
8
Excitation current, use motor rated current as 100%. (Valid
only when 00-21(P.300) or 00-22 (P.370) is set to 3~6)
9
Output torque, use two times motor rated torque as
100%.(Valid only when 00-21 (P.300) or 00-22 (P.370) is set
to 3~6)
10
Output power, use two times motor rated power as 100%.
11
High-speed pulse input, use 100KHz as 100%.
12
Motor speed, use 02-51 (P.55) as 100%
Usage of analog output terminal FM

For the calibration of terminal FM, please refer to 5.3.14 FM calibration parameter.
5.3.10 Terminal AM signal selection and processing
 Adjust terminal AM analog output type and level.
Parameter
Name
Default
Setting Range
Content
02-45
P.64
Terminal AM output
signal selection
0
0
Output 0~10V across terminal AM-5.
1
Reserved
2
Output 0~20mA across AM-5.
3
Output 4~20mA across AM-5.
02-46
P.191
AM output gain
935
0～1024
---
02-47
P.190
AM output bias
0
0～1024
---
Terminal AM signal selection and processing

Terminal AM output current/voltage is set by toggle switch SW2 on the control board with parameter 02-45
(P.64)
.
When selecting the output type of AM terminal, first dial toggle switch SW2 to correspond position, then set
02-45
(P.64)
value.
Setting
Setting
