Page #201 background image
PG feedback parameter group 09
PARAMETER DESCRIPTION 199
5.10 PG feedback parameter group 09
Group
Parameter
Number
Name
Setting Range
Default
Page
09-00
P.349
Encoder type
0:ABZ
0
199
1:ABZ (For synchronous motor)
2:Resolver 1x synchronous motor standard
encoder
3:ABZ/UVW synchronous motor standard
encoder
09-01
P.350
Encoder pulse 1
0~20000
1024
200
09-02
P.351
Encoder input type 1
0:Off
0
200
1:A/Phase B pulse wave,forward spin if Phase
A is over Phase B for 90 degrees
2:A/Phase B pulse wave,forward spin if Phase
B is over Phase A for 90 degrees.
3:Phase A :pulse wave,Phase B:directional
sign,L:reverse spin,H:forward spin
4:Phase A :pulse wave,Phase B: directional
sign,L:forward spin,H:reverse spin
09-03
P.352
PG error detection time
0~100.0s
1.0s
201
09-04
P.353
Overspeed detection
frequency
0~30.00Hz
4.00Hz
201
09-05
P.354
Overspeed detection time
0~100.0s
1.0s
201
09-06
P.355
Encoder pulse 2
0~20000
2500
202
09-07
P.356
Encoder input type 2
0:Off
0
202
1:A/Phase B pulse wave, forward spin if Phase
A is over Phase B for 90 degrees
2:A/Phase B pulse wave,forward spin if Phase
B is over Phase A for 90 degrees
3:Phase A :pulse wave,Phase B:directional
sign,L:reverse spin,H:forward spin
4:Phase A :pulse wave,Phase B: directional
sign,L:forward spin,H:reverse spin
09-08
P.357
Frequency division output
setting
1~255
1
203
09-09
P.358
Frequency division filter
coefficiency setting
0~255
0
203
09-10
P.359
Electronic gear ratio
0~300.00
1.00
203
