Shihlin electric SE3 Series User Manual

Tension control parameter group 14
PARAMETER DESCRIPTION 265

14-36
(P.636)
is for setting the friction compensation coefficiency.Take wind-up for instance, Material tension
decreases because of friction, especially with small rolls.Also,it makes tension nonlinear.It can be improved by
setting this parameter.
5.15.6 Material outage detection
 Supplementary function,not effective in all situations..
Parameter
Name
Default
Setting Range
Content
14-37
P.637
Material outage
detection
0
0
No detection
1
Material outage detection function 1
2
Material outage detection function 2
3
Material outage detection function 3
14-38
P.638
Minimum speed
detection
200.0
m/min
0.1～
6500.0m/min
Minimum linear speed detection when running out of
material
14-39
P.639
Error range detection
10.0%
0.1～100.0%
Error range detection when running out of material
14-40
P.640
Delay determination
2.0s
0.1～60.0s
Delay determination when running out of material
Material outage detection

The inverter automatically detects material outage through this parameter.This is a supplementary function,which
doesn`t apply to all situations.When not being able to get good results,set 14-37
(P.637)
to 0.

Material outage detection function 1:During operation,when using linear speed to calculate winding angle ,and
system linear speed is higher than 14-38
(P.638)
,inverter will detect if there is a outage of material according to
winding radius change,14-39
(P.639)
is used to set the error level of broken material detection.

Material outage detection function 2: In the running state, when the tension closed-loop PID is enabled and the line
speed is higher than 14-38 (P.638), the inverter detects the broken material according to the PID feedback status.
P639 (P.639) is used to set the broken PID feedback level with detection.

Material outage detection function 3: In the running state, the tension closed-loop PID is enabled, and the inverter
detects whether the material is broken according to the position of the floating roller.

When the system linear speed is higher than 14-38
(P.638)
，winding radius error (the current winding radius variation
is too big compared to the previous winding radius) exceeds the range set in 14-39
(P.639)
，and the error time is
over the delay time set in 14-40
(P.640)
，the inverter reports material outage failure(bEb)
Setting
