Shihlin electric SE3 Series User Manual

PG feedback parameter group 09
PARAMETER DESCRIPTION 187
5.9 PID parameter group 08
Group
Parameter
Number
Name
Setting Range
Default
Page
08-00
P.170
PID function selection
0: Off
0
189
0X: Parameter 08-03(P.225) as target value.
1X: Terminal 2-5 input as target source
2X: Terminal 4-5 input as target source
3X: Reserved
4X: Terminal M2 input as target source
X1: Terminal 2-5 input as feedback source
X2: Terminal 4-5 input as feedback source
X3:Reserved
08-01
P.171
PID feedback control
method
0: Negative feedback control.
0
189
1: Positive feedback control.
08-02
P.241
PID sampling period
0～60000 ms
20ms
189
08-03
P.225
PID target value
0～100.0%
20.0%
189
08-04
P.172
Proportional gain
0.1%～1000.0%
20.0%
189
08-05
P.173
Integral time
0～60.00s
1.00s
189
08-06
P.174
Differential time
0～10000ms
0ms
190
08-07
P.175
Abnormal deviation
0～100.0%
0.0%
190
08-08
P.176
Abnormal duration time
0~600.0s
30.0s
190
08-09
P.177
Abnormal processing mode
0: Stop freely
0
190
1: Slow down to stop
2: Alarm and continue operation
08-10
P.178
Sleep detection deviation
0～100.0%
0.0%
190
08-11
P.179
Sleep detection duration
time
0～255.0s
1.0s
192
08-12
P.180
Wake-up level
0～100.0%
90.0%
190
08-13
P.181
Stop level
0～120.00Hz
40.00Hz
190
08-14
P.182
Upper integral limit
0～200.0%
100.0%
190
08-15
P.183
Deceleration step length
when stable
0～10.00Hz
0.50Hz
190
08-20
P.641
Proportional gain P2
0.1%～1000.0%
20.0%
193
08-21
P.642
Integral time I2
0～60.00s
1.00s
193
08-22
P.643
Differential time D2
0～10000ms
0ms
193
