Analog input and output parameter group02
PARAMETER DESCRIPTION 96
5.3.1 Analog input terminals and M2 terminal function selection
Input function selection of terminal 2,4 and M2
Parameter
Name
Default
Setting Range
Content
02-00
P.500
Terminal 2-5 input
function
1
0
Off
1
Frequency command
2
Torque command
3
PID target value
4
PID feedback signal
5
Tension target value
6
Line speed
7
Line speed feedback
8
Real-time roll diameter
9
Initial roll diameter
10
Material thickness
11
PTC thermistor
12
PT100 thermistor
13
VF separate function
14
Positive torque limit
15
Negative torque limit
16
Positive/Negative torque limit
17
Regenerative torque limit
02-01
P.501
Terminal 4-5 input
function
1
Same as
02-00(P.500)
Same as 02-00(P.500)
02-02
P.504
Reserve
Reserve
---
---
02-03
P.503
Terminal HDI input
function
0
Same as
02-00(P.500)
Same as 02-00(P.500)
Input function selection
When set to 1 frequency command, 0~±10V / 4~20mA corresponds to 0~ maximum output frequency.
HDI is sharing terminal with M2 and default to M2 terminal function, set parameter 03-05(P.82) to 415457 as
HDI function.
Note: The default priority level is 2-5 > 4-5 >M2
