5.15.8 Constant linear speed mode
 Constant linear speed mode(14-00(P.600)=”4”)，used to select the method of acquiring the target constant linear
speed..
Parameter
Name
Default
Setting Range
Content
14-44
P.656
Line speed setting
source
0
0
Parameter 14-45（P.657）setting
1
Obtain linear speed via analog value or pulse input
2
Obtain linear speed via communication
14-45
P.657
Line speed setting
0.0
m/min
0～6500.0m/min
Linear speed setting value
Linear speed setting source
 When 14-44(P.656)=0, linear speed is set by parameter 14-45(P.657).
 The linear speed is obtained by analog value or pulse input（14-44(P.656)=“1”）
The maximum linear speed 14-30(P.628) must be set correctly.The maximum analog value and pulse input
corresponds to the maximum linear speed.
 Obtain linear speed through communication（14-44(P.656)=“2）
Set address H100B through modbus.The setting range is 0~6500.0m/min
5.15.9 Tension closed-loop limiter
 Closed-loop speed control mode（14-00(P.600)=“2”）， used to select the PID regulator output limit benchmark and
limit bias.
Group
Parameter number
Default
Setting Range
content
14-46
P.658
Tension closed-loop
limit standard
0
0
Motor frequency as limit standard
1
Actual system linear speed as limit standard
14-47
P.659
Tension closed-loop limit
bias
0.0%
0.0%~100.0%
Control limit bias by tension closed-loop
 Under closed-loop speed control mode, PID regulator limiter bias is set by 14-17(P.659). If this parameter is set to
0,when the system is at zero speed, the controller will not work. Appropriately setting bias can avoid this problem.
